BTEL / PTUL5000 pressure transmitters

The BTEL / PTUL5000 differential pressure transmitters from 1 mbar / 1 inH2O are based on piezoresistive pressure sensors and are are intended to be used with dry and non-corrosive gases. They provide two threaded pressure ports. The transmitters are calibrated and temperature compensated and offer different amplified analogue output signals. All BTEL / PTUL5000 pressure transmitters can be modified according to customer specific requirements.

Typical applications include industrial measurement and control, HVAC, medical devices and instrumentation.

Downloads
BTEL / PTUL5000 pressure transmitter
Technical specifications
Pressure ranges Gage


Gage (Pressure/Vacuum)


Differential		 0...1 to 0...10 mbar
0...1 to 0...10 inH2O

0...±1 to 0...±10 mbar
0...±1 to 0...±10 inH2O

0...1 to 0...10 mbar
0...1 to 0...10 inH2O
0...±1 to 0...±10 mbar
0...±1 to 0...±10 inH2O
Output signal   1...6 V, 4...20 mA
Non-linearity and hysteresis (typical, combined)   ±0.1 %FSO
Pressure connection   G 1/8, 1/8 NPT
Size without nipples and pins (approx.)   Ø 40 x 72 mm
